Rơ-le quang 24VDC 20kHz 0.2A MIRO 6652511
– IN: 30 VDC
– OUT: 48 VDC / 0.2 A
– 6.2 mm spring clamp
– Kích thước (mm): 91 x 62 x 70
Rơ-le quang 24VDC 20kHz 0.2A MIRO 6652511: Một module opto-coupler dùng để cách ly tín hiệu trong các hệ thống điều khiển công nghiệp
– IN: 30 VDC
– OUT: 48 VDC / 0.2 A
– 6.2 mm spring clamp
– Kích thước (mm): 91 x 62 x 70
THÔNG SỐ KỸ THUẬT – Rơ-le quang 24VDC 20kHz 0.2A MIRO 6652511
Header
| Material short text | MIRO-TR,24VDC,20KHZ,IN<1MA,FK |
Electrical data | Input
| Input voltage DC min. | 15 V |
| Input voltage DC max. | 30 V |
| Input voltage OFF DC min. | 0 V |
| Input voltage OFF DC max. | 2 V |
| Input current DC max. | 16 mA |
| Control current | 0.1 mA |
Electrical data | Output
| Voltage drop DC max. | 12 V |
| Quiescent current OFF max. | 0.1 mA |
| Switch on delay max. | 10 µs |
| Switch off delay max. | 18 µs |
| Voltage switching DC min. | 5 V |
| Switching voltage DC max. | 48 V |
| Switching current min. | 0.1 mA |
| Switching current max. | 0.2 A |
| Switching frequency max. | 20,000 Hz |
Diagnostics
| Status indication LED | yellow |
Device protection | Electrical
| Rated insulation voltage | 3,750 V |
Device protection | Media
| Flame resistance | flame retardant |
Mechanical data | Material data
| Material housing | Plastic |
| Color housing | black |
Mechanical data | Mounting data
| Height | 91 mm |
| Width | 62 mm |
| Depth | 70 mm |
| Mounting method | geschnappt |
| Suitable for mounting type | (EN 60715), mounting rail |
Environmental characteristics | Climatic
| Operating temperature min. | -20 °C |
| Operating temperature max. | 60 °C |
