Mô-đun I/O ET 200M 16DI SM321 6ES7 321-1BH02-0AA0
– 16 ngõ vào digital 24VDC
– Connector 20-pin
– 2-wire connection
– 24VDC
– IP20
Mô-đun I/O ET 200M 16DI SM321 6ES7 321-1BH02-0AA0: là mô-đun electronic I/O mở rộng thuộc họ S7-300 của Siemens với 16 ngõ vào digital 24VDC
– Connector 20-pin
– 2-wire connection
– 24VDC
Kích thước: 125H x 40W x 120D mm
Thông số kỹ thuật – Mô-đun I/O ET 200M 16DI SM321 6ES7 321-1BH02-0AA0
| Product | ||
| Article Number (Market Facing Number) | 6ES7321-1BH02-0AA0 | |
| Product Description | ***spare part*** SIMATIC S7-300, digital input SM 321, isolated, 16 DI, 24 V DC, 1x 20-pole | |
| Product family | Not available | |
| Product Lifecycle (PLM) | PM410:Product cancellation | |
| PLM Effective Date | Product is cancelled since: 01.10.2025 | |
| Notes |
This product is a Spare Part, please visit the Spares & Service section for more information
If you need assistance please contact our local Siemens office
|
|
| Price data | ||
| Price Group | S20 | |
| List Price | Show prices | |
| Customer Price | Show prices | |
| Metal Factor | None | |
| Delivery information | ||
| Export Control Regulations | ECCN : 9N9999 / AL : N | |
| Standard lead time ex-works | 1 Day/Days | |
| Net Weight (kg) | 0,237 Kg | |
| Packaging Dimension | 12,80 x 15,20 x 5,00 | |
| Package size unit of measure | CM | |
| Quantity Unit | 1 Piece | |
| Packaging Quantity | 1 | |
| Additional Product Information | ||
| EAN | 4025515051893 | |
| UPC | 040892561715 | |
| Commodity Code | 85389091 | |
| LKZ_FDB/ CatalogID | ST73 | |
| Product Group | 4561 | |
| Group Code | R135 | |
| Country of origin | Germany | |
| Compliance with the substance restrictions according to RoHS directive | Since: 31.03.2008 | |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | |
| WEEE (2012/19/EU) Take-Back Obligation | Yes | |
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
|
| SCIP number | 9f4d53a8-ee62-4441-9f1c-0f959577dfc1 | |
